Widely applied in lifting and transport machinery across construction, energy, mining, transportation and logisticssectors.In construction sector for tower cranes and overhead lifting equipment,Supports power transmission towers andwind turbine installation in energy industry;Covers both surface and underground operations in mining machinery.Port,railway, highway and airport equipment feature dedicated cabs ensuring safe and eficient operation.

Structure&Materials

Externally constructed with 2.0mm cold-rolled steelwelding, featuring extruded profiles and bent steel panecomposite framework.Interior finished with formicapanels,complete with powder coating for corrosionprotection.

Safety Features

5mm tempered glass windows,aluminum alloy slidingwindows, industrial-grade doorlocks and safetyguardrails ensure optimal visibility and operationalsecurity.

Design Characteristics

Lightweight high-load-bearing framework with modularassembly, engineered forharsh operatingconditions whilemeeting lS06385 ergonomic standards.

01 Alarm Device

02 Emergency Luminaire

03 Air ConditioningUnit

04 Coordinated ControlConsole

05 Curtain Assembly

06 Leatherette&SteelPanelInterior

07 Access Walkway

08 AncillaryAccessories
